public Map getFlights() {
  // use a tree map, to make sure it's sorted
  TreeMap map = new TreeMap();
  map.put("KL1117", "Stockholm");
  ...
  return map;
}

<element name="GetFlightsRequest">
  <complexType>
    <all>
      <element name="departureDate" type="date"/>
      <element name="from" type="string"/>
      <element name="to" type="string"/>
    </all>
  </complexType>
</element>

public class Flight {
  private String number;
  private List<Passenger> passengers;

  // getters and setters omitted
}

public class Passenger {
  private String name;
  private Flight flight;

  // getters and setters omitted
}

<flight number="KL1117">
  <passengers>
    <passenger>
      <name>Arjen Poutsma</name>
      <flight number="KL1117">
        <passengers>
          <passenger>
            <name>Arjen Poutsma</name>
            <flight number="KL1117">
              <passengers>
                <passenger>
                   <name>Arjen Poutsma</name>
                   ...

<flight number="KL1117">
  <passengers>
    <passenger>
      <name>Arjen Poutsma</name>
      <flight href="KL1117" />
    </passenger>
    ...
  </passengers>
</flight>

<simpleType name="AirportCode">
    <restriction base="string">
        <pattern value="[A-Z][A-Z][A-Z]"/>
    </restriction>
</simpleType>

<Holiday xmlns="http://mycompany.com/hr/schemas">
    <StartDate>2006-07-03</StartDate>
    <EndDate>2006-07-07</EndDate>
</Holiday>

<Employee xmlns="http://mycompany.com/hr/schemas">
    <Number>42</Number>
    <FirstName>Arjen</FirstName>
    <LastName>Poutsma</LastName>
</Employee>

<HolidayRequest xmlns="http://mycompany.com/hr/schemas">
    <Holiday>
        <StartDate>2006-07-03</StartDate>
        <EndDate>2006-07-07</EndDate>
    </Holiday>
    <Employee>
        <Number>42</Number>
        <FirstName>Arjen</FirstName>
        <LastName>Poutsma</LastName>
    </Employee>
</HolidayRequest>

package com.mycompany.hr.ws;

import java.text.ParseException;
import java.text.SimpleDateFormat;
import java.util.Arrays;
import java.util.Date;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.ws.server.endpoint.annotation.Endpoint;
import org.springframework.ws.server.endpoint.annotation.PayloadRoot;
import org.springframework.ws.server.endpoint.annotation.RequestPayload;

import com.mycompany.hr.service.HumanResourceService;
import org.jdom2.Element;
import org.jdom2.JDOMException;
import org.jdom2.Namespace;
import org.jdom2.filter.Filters;
import org.jdom2.xpath.XPathExpression;
import org.jdom2.xpath.XPathFactory;

@Endpoint                                                                                     (1)
public class HolidayEndpoint {

    private static final String NAMESPACE_URI = "http://mycompany.com/hr/schemas";

    private XPathExpression<Element> startDateExpression;

    private XPathExpression<Element> endDateExpression;

    private XPathExpression<Element> firstNameExpression;

    private XPathExpression<Element> lastNameExpression;

    private HumanResourceService humanResourceService;

    @Autowired                                                                                (2)
    public HolidayEndpoint(HumanResourceService humanResourceService) throws JDOMException {
        this.humanResourceService = humanResourceService;

        Namespace namespace = Namespace.getNamespace("hr", NAMESPACE_URI);
        XPathFactory xPathFactory = XPathFactory.instance();
        startDateExpression = xPathFactory.compile("//hr:StartDate", Filters.element(), null, namespace);
        endDateExpression = xPathFactory.compile("//hr:EndDate", Filters.element(), null, namespace);
        firstNameExpression = xPathFactory.compile("//hr:FirstName", Filters.element(), null, namespace);
        lastNameExpression = xPathFactory.compile("//hr:LastName", Filters.element(), null, namespace);
    }

    @PayloadRoot(namespace = NAMESPACE_URI, localPart = "HolidayRequest")                      (3)
    public void handleHolidayRequest(@RequestPayload Element holidayRequest) throws Exception {(4)
        Date startDate = parseDate(startDateExpression, holidayRequest);
        Date endDate = parseDate(endDateExpression, holidayRequest);
        String name = firstNameExpression.evaluateFirst(holidayRequest).getText() + " " + lastNameExpression.evaluateFirst(holidayRequest).getText();

        humanResourceService.bookHoliday(startDate, endDate, name);
    }

    private Date parseDate(XPathExpression<Element> expression, Element element) throws ParseException {
        Element result = expression.evaluateFirst(element);
        if (result != null) {
            SimpleDateFormat dateFormat = new SimpleDateFormat("yyyy-MM-dd");
            return dateFormat.parse(result.getText());
        } else {
            throw new IllegalArgumentException("Could not evaluate [" + expression + "] on [" + element + "]");
        }
    }

}

<dependencies>
    <dependency>
        <groupId>org.springframework.ws</groupId>
        <artifactId>spring-ws-core</artifactId>
        <version></version>
    </dependency>
    <dependency>
        <groupId>jdom</groupId>
        <artifactId>jdom</artifactId>
        <version>2.0.1</version>
    </dependency>
    <dependency>
        <groupId>jaxen</groupId>
        <artifactId>jaxen</artifactId>
        <version>1.1</version>
    </dependency>
</dependencies>

<beans xmlns="http://www.springframework.org/schema/beans"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
  xmlns:context="http://www.springframework.org/schema/context"
  xmlns:sws="http://www.springframework.org/schema/web-services"
  xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-3.0.xsd
  http://www.springframework.org/schema/web-services http://www.springframework.org/schema/web-services/web-services-2.0.xsd
  http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context-3.0.xsd">

  <context:component-scan base-package="com.mycompany.hr"/>

  <sws:annotation-driven/>

</beans>

@PayloadRoot(namespace = "http://mycompany.com/hr/schemas", localPart = "HolidayRequest")

package com.mycompany.hr.service;

import java.util.Date;

public interface HumanResourceService {
    void bookHoliday(Date startDate, Date endDate, String name);
}

package com.mycompany.hr.service;

import java.util.Date;

import org.springframework.stereotype.Service;

@Service                                                                 (1)
public class StubHumanResourceService implements HumanResourceService {
    public void bookHoliday(Date startDate, Date endDate, String name) {
        System.out.println("Booking holiday for [" + startDate + "-" + endDate + "] for [" + name + "] ");
    }
}

<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
          http://www.springframework.org/schema/beans/spring-beans-2.0.xsd">

    <bean id="nameExpression" class="org.springframework.xml.xpath.XPathExpressionFactoryBean">
        <property name="expression" value="/Contacts/Contact/Name"/>
    </bean>

    <bean id="myEndpoint" class="sample.MyXPathClass">
        <constructor-arg ref="nameExpression"/>
    </bean>

</beans>

package sample;

public class MyXPathClass {

    private final XPathExpression nameExpression;

    public MyXPathClass(XPathExpression nameExpression) {
        this.nameExpression = nameExpression;
    }

    public void doXPath(Document document) {
        String name = nameExpression.evaluateAsString(document.getDocumentElement());
        System.out.println("Name: " + name);
    }

}

package sample;

public class MyXPathClass  {

   private final XPathExpression contactExpression;

   public MyXPathClass(XPathExpression contactExpression) {
      this.contactExpression = contactExpression;
   }

   public void doXPath(Document document) {
      List contacts = contactExpression.evaluate(document,
        new NodeMapper() {
           public Object mapNode(Node node, int nodeNum) throws DOMException {
              Element contactElement = (Element) node;
              Element nameElement = (Element) contactElement.getElementsByTagName("Name").item(0);
              Element phoneElement = (Element) contactElement.getElementsByTagName("Phone").item(0);
              return new Contact(nameElement.getTextContent(), phoneElement.getTextContent());
           }
        });
      PlainText Section qName; // do something with the list of Contact objects
   }
}

package sample;

public class MyXPathClass {

    private XPathOperations template = new Jaxp13XPathTemplate();

    public void doXPath(Source source) {
        String name = template.evaluateAsString("/Contacts/Contact/Name", request);
        // do something with name
    }

}

<web-app>

    <servlet>
        <servlet-name>spring-ws</servlet-name>
        <servlet-class>org.springframework.ws.transport.http.MessageDispatcherServlet</servlet-class>
        <load-on-startup>1</load-on-startup>
    </servlet>

    <servlet-mapping>
        <servlet-name>spring-ws</servlet-name>
        <url-pattern>/*</url-pattern>
    </servlet-mapping>

</web-app>

public class MyServletInitializer
    extends AbstractAnnotationConfigMessageDispatcherServletInitializer {

    @Override
    protected Class<?>[] getRootConfigClasses() {
        return new Class[]{MyRootConfig.class};
    }

    @Override
    protected Class<?>[] getServletConfigClasses() {
        return new Class[]{MyEndpointConfig.class};
    }

}

<beans>

    <bean class="org.springframework.ws.transport.http.WebServiceMessageReceiverHandlerAdapter"/>

    <bean class="org.springframework.web.servlet.handler.SimpleUrlHandlerMapping">
        <property name="defaultHandler" ref="messageDispatcher"/>
    </bean

    <bean id="messageDispatcher" class="org.springframework.ws.soap.server.SoapMessageDispatcher"/>

    ...

    <bean class="org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerAdapter"/>

</beans>

<beans>

    <bean class="org.springframework.ws.transport.http.WebServiceMessageReceiverHandlerAdapter"/>

    <bean class="org.springframework.ws.transport.http.WsdlDefinitionHandlerAdapter"/>

    <bean class="org.springframework.web.servlet.handler.SimpleUrlHandlerMapping">
        <property name="mappings">
           <props>
             <prop key="*.wsdl">myServiceDefinition</prop>
           </props>
        </property>
        <property name="defaultHandler" ref="messageDispatcher"/>
    </bean>

    <bean id="messageDispatcher" class="org.springframework.ws.soap.server.SoapMessageDispatcher"/>

    <bean id="myServiceDefinition" class="org.springframework.ws.wsdl.wsdl11.SimpleWsdl11Definition">
       <prop name="wsdl" value="/WEB-INF/myServiceDefintion.wsdl"/>
    </bean>

    ...

</beans>

<beans>

    <bean id="connectionFactory" class="org.apache.activemq.ActiveMQConnectionFactory">
        <property name="brokerURL" value="vm://localhost?broker.persistent=false"/>
    </bean>

    <bean id="messageFactory" class="org.springframework.ws.soap.saaj.SaajSoapMessageFactory"/>

    <bean class="org.springframework.jms.listener.DefaultMessageListenerContainer">
        <property name="connectionFactory" ref="connectionFactory"/>
        <property name="destinationName" value="RequestQueue"/>
        <property name="messageListener">
            <bean class="org.springframework.ws.transport.jms.WebServiceMessageListener">
                <property name="messageFactory" ref="messageFactory"/>
                <property name="messageReceiver" ref="messageDispatcher"/>
            </bean>
        </property>
    </bean>

    <bean id="messageDispatcher" class="org.springframework.ws.soap.server.SoapMessageDispatcher">
        <property name="endpointMappings">
            <bean
              class="org.springframework.ws.server.endpoint.mapping.PayloadRootAnnotationMethodEndpointMapping">
                <property name="defaultEndpoint">
                    <bean class="com.example.MyEndpoint"/>
                </property>
            </bean>
        </property>
    </bean>
</beans>

<beans>

    <bean id="messageFactory" class="org.springframework.ws.soap.saaj.SaajSoapMessageFactory"/>

    <bean id="messagingReceiver" class="org.springframework.ws.transport.mail.MailMessageReceiver">
        <property name="messageFactory" ref="messageFactory"/>
        <property name="from" value="Spring-WS SOAP Server &lt;[email protected] (英語)  &gt;"/>
        <property name="storeUri" value="imap://server:[email protected] (英語)  /INBOX"/>
        <property name="transportUri" value="smtp://smtp.example.com"/>
        <property name="messageReceiver" ref="messageDispatcher"/>
        <property name="monitoringStrategy">
            <bean class="org.springframework.ws.transport.mail.monitor.PollingMonitoringStrategy">
                <property name="pollingInterval" value="30000"/>
            </bean>
        </property>
    </bean>

    <bean id="messageDispatcher" class="org.springframework.ws.soap.server.SoapMessageDispatcher">
        <property name="endpointMappings">
            <bean
              class="org.springframework.ws.server.endpoint.mapping.PayloadRootAnnotationMethodEndpointMapping">
                <property name="defaultEndpoint">
                    <bean class="com.example.MyEndpoint"/>
                </property>
            </bean>
        </property>
    </bean>
</beans>

<beans>

    <bean id="messageFactory" class="org.springframework.ws.soap.saaj.SaajSoapMessageFactory"/>

    <bean id="messageReceiver" class="org.springframework.ws.soap.server.SoapMessageDispatcher">
        <property name="endpointMappings" ref="endpointMapping"/>
    </bean>

    <bean id="endpointMapping" class="org.springframework.ws.server.endpoint.mapping.PayloadRootAnnotationMethodEndpointMapping">
        <property name="defaultEndpoint" ref="stockEndpoint"/>
    </bean>

    <bean id="httpServer" class="org.springframework.remoting.support.SimpleHttpServerFactoryBean">
        <property name="contexts">
            <map>
                <entry key="/StockService.wsdl" value-ref="wsdlHandler"/>
                <entry key="/StockService" value-ref="soapHandler"/>
            </map>
        </property>
    </bean>

    <bean id="soapHandler" class="org.springframework.ws.transport.http.WebServiceMessageReceiverHttpHandler">
        <property name="messageFactory" ref="messageFactory"/>
        <property name="messageReceiver" ref="messageReceiver"/>
    </bean>

    <bean id="wsdlHandler" class="org.springframework.ws.transport.http.WsdlDefinitionHttpHandler">
        <property name="definition" ref="wsdlDefinition"/>
    </bean>
</beans>

<beans>

    <bean id="messageFactory" class="org.springframework.ws.soap.saaj.SaajSoapMessageFactory"/>

    <bean id="connection" class="org.springframework.ws.transport.xmpp.support.XmppConnectionFactoryBean">
        <property name="host" value="jabber.org"/>
        <property name="username" value="username"/>
        <property name="password" value="password"/>
    </bean>

    <bean id="messagingReceiver" class="org.springframework.ws.transport.xmpp.XmppMessageReceiver">
        <property name="messageFactory" ref="messageFactory"/>
        <property name="connection" ref="connection"/>
        <property name="messageReceiver" ref="messageDispatcher"/>
    </bean>

    <bean id="messageDispatcher" class="org.springframework.ws.soap.server.SoapMessageDispatcher">
        <property name="endpointMappings">
            <bean
              class="org.springframework.ws.server.endpoint.mapping.PayloadRootAnnotationMethodEndpointMapping">
                <property name="defaultEndpoint">
                    <bean class="com.example.MyEndpoint"/>
                </property>
            </bean>
        </property>
    </bean>

</beans>

@PayloadRoot(localPart = "order", namespace = "http://samples")
public void order(@RequestPayload Element orderElement) {
  Order order = createOrder(orderElement);
  orderService.createOrder(order);
}

<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://www.w3.org/2003/05/soap-envelope"
    xmlns:wsa="http://www.w3.org/2005/08/addressing">
  <SOAP-ENV::Header>
    <wsa:MessageID>urn:uuid:21363e0d-2645-4eb7-8afd-2f5ee1bb25cf</wsa:MessageID>
    <wsa:ReplyTo>
      <wsa:Address>http://example.com/business/client1</wsa:Address>
    </wsa:ReplyTo>
    <wsa:To S:mustUnderstand="true">http://example/com/fabrikam</wsa:To>
    <wsa:Action>http://example.com/fabrikam/mail/Delete</wsa:Action>
  </SOAP-ENV:Header>
  <SOAP-ENV:Body>
    <f:Delete xmlns:f="http://example.com/fabrikam">
      <f:maxCount>42</f:maxCount>
    </f:Delete>
  </SOAP-ENV:Body>
</SOAP-ENV:Envelope>

<sws:interceptors>
  <bean class="samples.MyGlobalInterceptor"/>
  <sws:payloadRoot namespaceUri="http://www.example.com">
    <bean class="samples.MyPayloadRootInterceptor"/>
  </sws:payloadRoot>
  <sws:soapAction value="http://www.example.com/SoapAction">
    <bean class="samples.MySoapActionInterceptor1"/>
    <ref bean="mySoapActionInterceptor2"/>
  </sws:soapAction>
</sws:interceptors>

<bean id="mySoapActionInterceptor2" class="samples.MySoapActionInterceptor2"/>

@Configuration
@EnableWs
public class MyWsConfiguration extends WsConfigurerAdapter {

  @Override
  public void addInterceptors(List<EndpointInterceptor> interceptors) {
    interceptors.add(new MyPayloadRootInterceptor());
  }

}

<beans>
    <bean id="exceptionResolver"
        class="org.springframework.ws.soap.server.endpoint.SoapFaultMappingExceptionResolver">
        <property name="defaultFault" value="SERVER"/>
        <property name="exceptionMappings">
            <value>
                org.springframework.oxm.ValidationFailureException=CLIENT,Invalid request
            </value>
        </property>
    </bean>
</beans>

<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/">
    <SOAP-ENV:Body>
       <SOAP-ENV:Fault>
           <faultcode>SOAP-ENV:Client</faultcode>
           <faultstring>Invalid request</faultstring>
       </SOAP-ENV:Fault>
    </SOAP-ENV:Body>
</SOAP-ENV:Envelope>

package samples;

import org.springframework.ws.soap.server.endpoint.annotation.FaultCode;
import org.springframework.ws.soap.server.endpoint.annotation.SoapFault;

@SoapFault(faultCode = FaultCode.SERVER)
public class MyBusinessException extends Exception {

    public MyClientException(String message) {
        super(message);
    }
}

<SOAP-ENV:Envelope xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/">
    <SOAP-ENV:Body>
       <SOAP-ENV:Fault>
           <faultcode>SOAP-ENV:Server</faultcode>
           <faultstring>Oops!</faultstring>
       </SOAP-ENV:Fault>
    </SOAP-ENV:Body>
</SOAP-ENV:Envelope>

import org.springframework.ws.server.endpoint.annotation.Endpoint;
import org.springframework.ws.server.endpoint.annotation.RequestPayload;
import org.springframework.ws.server.endpoint.annotation.ResponsePayload;

@Endpoint                                                                (1)
public class CustomerEndpoint {

  @ResponsePayload                                                       (2)
  public CustomerCountResponse getCustomerCount(                         (2)
      @RequestPayload CustomerCountRequest request) {                    (2)
    CustomerCountResponse response = new CustomerCountResponse();
    response.setCustomerCount(10);
    return response;
  }

}

import javax.xml.transform.Source;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.ApplicationContext;
import org.springframework.test.context.ContextConfiguration;
import org.springframework.test.context.junit4.SpringJUnit4ClassRunner;
import org.springframework.xml.transform.StringSource;

import org.junit.Before;
import org.junit.Test;
import org.junit.runner.RunWith;

import org.springframework.ws.test.server.MockWebServiceClient;                       (1)
import static org.springframework.ws.test.server.RequestCreators.*;                   (1)
import static org.springframework.ws.test.server.ResponseMatchers.*;                  (1)

@RunWith(SpringJUnit4ClassRunner.class)                                               (2)
@ContextConfiguration("spring-ws-servlet.xml")                                        (2)
public class CustomerEndpointIntegrationTest {

  @Autowired
  private ApplicationContext applicationContext;                                      (3)

  private MockWebServiceClient mockClient;

  @Before
  public void createClient() {
    mockClient = MockWebServiceClient.createClient(applicationContext);               (4)
  }

  @Test
  public void customerEndpoint() throws Exception {
    Source requestPayload = new StringSource(
      "<customerCountRequest xmlns='http://springframework.org/spring-ws'>" +
        "<customerName>John Doe</customerName>" +
      "</customerCountRequest>");
    Source responsePayload = new StringSource(
      "<customerCountResponse xmlns='http://springframework.org/spring-ws'>" +
        "<customerCount>10</customerCount>" +
      "</customerCountResponse>");

    mockClient.sendRequest(withPayload(requestPayload)).                              (5)
      andExpect(payload(responsePayload));                                            (5)
  }
}

public interface RequestCreator {

  WebServiceMessage createRequest(WebServiceMessageFactory messageFactory)
    throws IOException;

}

public interface ResponseMatcher {

    void match(WebServiceMessage request,
               WebServiceMessage response)
      throws IOException, AssertionError;

}

mockClient.sendRequest(...).
 andExpect(payload(expectedResponsePayload)).
 andExpect(validPayload(schemaResource));

import java.io.StringReader;
import javax.xml.transform.stream.StreamResult;
import javax.xml.transform.stream.StreamSource;

import org.springframework.ws.WebServiceMessageFactory;
import org.springframework.ws.client.core.WebServiceTemplate;
import org.springframework.ws.transport.WebServiceMessageSender;

public class WebServiceClient {

    private static final String MESSAGE =
        "<message xmlns=\"http://tempuri.org\">Hello, Web Service World</message>";

    private final WebServiceTemplate webServiceTemplate = new WebServiceTemplate();

    public void setDefaultUri(String defaultUri) {
        webServiceTemplate.setDefaultUri(defaultUri);
    }

    // send to the configured default URI
    public void simpleSendAndReceive() {
        StreamSource source = new StreamSource(new StringReader(MESSAGE));
        StreamResult result = new StreamResult(System.out);
        webServiceTemplate.sendSourceAndReceiveToResult(source, result);
    }

    // send to an explicit URI
    public void customSendAndReceive() {
        StreamSource source = new StreamSource(new StringReader(MESSAGE));
        StreamResult result = new StreamResult(System.out);
        webServiceTemplate.sendSourceAndReceiveToResult("http://localhost:8080/AnotherWebService",
            source, result);
    }

}

<beans xmlns="http://www.springframework.org/schema/beans">

    <bean id="webServiceClient" class="WebServiceClient">
        <property name="defaultUri" value="http://localhost:8080/WebService"/>
    </bean>

</beans>

public void marshalWithSoapActionHeader(MyObject o) {

    webServiceTemplate.marshalSendAndReceive(o, new WebServiceMessageCallback() {

        public void doWithMessage(WebServiceMessage message) {
            ((SoapMessage)message).setSoapAction("http://tempuri.org/Action");
        }
    });
}

public void marshalWithSoapActionHeader(final Source s) {
    final Transformer transformer = transformerFactory.newTransformer();
    webServiceTemplate.sendAndReceive(new WebServiceMessageCallback() {
        public void doWithMessage(WebServiceMessage message) {
            transformer.transform(s, message.getPayloadResult());
        },
        new WebServiceMessageExtractor() {
            public Object extractData(WebServiceMessage message) throws IOException {
                // do your own transforms with message.getPayloadResult()
                //     or message.getPayloadSource()
            }
          }
        });
}

import org.springframework.ws.client.core.support.WebServiceGatewaySupport;

public class CustomerClient extends WebServiceGatewaySupport {                          (1)

  public int getCustomerCount() {
    CustomerCountRequest request = new CustomerCountRequest();                          (2)
    request.setCustomerName("John Doe");

    CustomerCountResponse response =
      (CustomerCountResponse) getWebServiceTemplate().marshalSendAndReceive(request);   (3)

    return response.getCustomerCount();
  }

}

import javax.xml.transform.Source;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.test.context.ContextConfiguration;
import org.springframework.test.context.junit4.SpringJUnit4ClassRunner;
import org.springframework.xml.transform.StringSource;

import org.junit.Before;
import org.junit.Test;
import org.junit.runner.RunWith;

import static org.junit.Assert.assertEquals;

import org.springframework.ws.test.client.MockWebServiceServer;                         (1)
import static org.springframework.ws.test.client.RequestMatchers.*;                     (1)
import static org.springframework.ws.test.client.ResponseCreators.*;                    (1)

@RunWith(SpringJUnit4ClassRunner.class)                                                 (2)
@ContextConfiguration("integration-test.xml")                                           (2)
public class CustomerClientIntegrationTest {

  @Autowired
  private CustomerClient client;                                                        (3)

  private MockWebServiceServer mockServer;                                              (4)

  @Before
  public void createServer() throws Exception {
    mockServer = MockWebServiceServer.createServer(client);
  }

  @Test
  public void customerClient() throws Exception {
    Source requestPayload = new StringSource(
      "<customerCountRequest xmlns='http://springframework.org/spring-ws'>" +
        "<customerName>John Doe</customerName>" +
      "</customerCountRequest>");
    Source responsePayload = new StringSource(
      "<customerCountResponse xmlns='http://springframework.org/spring-ws'>" +
        "<customerCount>10</customerCount>" +
      "</customerCountResponse>");

    mockServer.expect(payload(requestPayload)).andRespond(withPayload(responsePayload));(5)

    int result = client.getCustomerCount();                                             (6)
    assertEquals(10, result);                                                           (6)

    mockServer.verify();                                                                (7)
  }

}

public interface RequestMatcher {

  void match(URI uri,
             WebServiceMessage request)
    throws IOException,
           AssertionError;
}

mockServer.expect(connectionTo("http://example.com")).
 andExpect(payload(expectedRequestPayload)).
 andExpect(validPayload(schemaResource)).
 andRespond(...);

public interface ResponseCreator {

  WebServiceMessage createResponse(URI uri,
                                   WebServiceMessage request,
                                   WebServiceMessageFactory messageFactory)
    throws IOException;

}

<bean class="org.springframework.ws.soap.security.wss4j.Wss4jSecurityInterceptor">
    <property name="validationActions" value="UsernameToken Encrypt"/>
    ...
    <property name="securementActions" value="Encrypt"/>
    ...
</bean>
